ISD1760 Series Voice Record / Playback ISD1700 Series Board

Product Information

This ISD1700 voice module is fast
An ISD1700 series chip design with a simple and practical circuit board.
It is suitable for ISD1700 full series chips, with simple operation, function complete design etc.
ISD1700 series recording chip is a kind of high integration, high performance chip. It can have multiple recordings, sampling rate can be in 4 k to 12 k
, power supply range can be between  2.4 V to 5.5 V.
ISD1700 has a new recording hint function, when a new recording, LED back to every few seconds flash a to prompt the user a new recording. In addition there are 4 sound to prompt the user's operation results, such as start recording, stop the recording, erase, the next song and all erasure, etc. The recording data storage in the chips is FLASH memory, without any compression, so good quality and disconnection of supply storage.
Chips have two independent speech signal input channels, microphone input and analog signal input.
In the independent key mode, when a certain function operation after completion of the chip will automatically enter power down mode to reduce power consumption.
In the SPI mode, users can to chips for more multi-purpose operation. As for any memory address for recording, Analog channel configuration register (Analog Path Configuration register, APC) such as reading and writing.

Size: 52x 55mm
Power supply:  DC5V
The recording time: 6K/75Sec, 8K/60Sec
Frequency 6 KHz or 8 KHz
Power LED, IC LED
Simple operation , not need to SCM or other module work direct
Output all PIN For Chip control , Convenient for control


Please note: no support for this device, ISD1760 is supplied

1x ISD1700 voice module Supplied
